Fiberglass 0 or 90 degree unidirectional fabric used for composite
Fiberglass 0 or 90 degree unidirectional fabric used for composite is stitched-bonded composite reinforcement combining continuous roving oriented in the 0° or 90° direction into single fabric. It can be with mat or without mat. It is ideal for applications such as wind blades, marine panel, snowboards, truck and trailer panel,,,
Property:
Typical Type:
| Items |
Total Weight (G/M2) |
0° Roving density(G/M2) | 90° Roving Density(G/M2) | Chop Density(G/M2) | Polyester Yarn Density(G/M2) |
| STR-UF300 | 312 | 261 | 39 | / | 12 |
| STR-UF400 | 412 | 355 | 45 | / | 12 |
| STR-UF460 | 469.5 | 413 | 47 | / | 9.5 |
| STR-UF600A | 612 | 533 | 67 | / | 12 |
| STR-UF600 | 612 | 480 | 120 | / | 12 |
| STR-UF800 | 812 | 710 | 90 | / | 12 |
| STR-UF950 | 956 | 866 | 84 | / | 6 |
| STR-UF1000 | 1022 | 710 | / | 300 | 12 |
| STR-UF1200 | 1195 | 1134 | 55 | / | 6 |
| STR-UF125 | 126 | 120 | / | 6 | |
| STR-UFC450 | 459.5 | 250 | 200 | 9.5 | |
| STR-UFC500 | 509.5 | 300 | 200 | 9.5 | |
| STR-UFC600 | 609.5 | 300 | 300 | 9.5 | |
| STR-UFC800 | 809.5 | 500 | 300 | 9.5 | |
| STR-UFC900 | 909.5 | 600 | 300 | 9.5 |
Remarks:
Standard width: 127cm, Min.width 5cm
Standard roll weight: 50kg~55kg
E-glass:EWR200,EWR300,EWR400,EWR450,EWR500,EWR600,EWR800
Characteristics
1. No binder
2. Good resin flowability and impregnation capability
3. Suitable for thick molded components because of its strong tenacity.
4. Easily fills the mold and conforms to complex shapes, while
providing a smooth finished surface.
5. It is fluey and convenient for running.
PACKAGE:
Plastic bag
Specifications
| Core diameter | 2 inches or 3 inches |
| Weight/m3 | 200g~900g |
| Width: | 1040mm or some other width |
| Weight/roll: | 28kgs or some other weight |
| Color: | white color |
Feature
| Certificate: | TDS, Test report, SGS, ISO9001, ETAG004 |
| Place of Origin: | Made-In-China |
Packing
| 1. | Each roll will be packed into one plastic bag. Some rolls will be packed into carton without pallet. At last load into the container. |
| 2. | Each roll will be packed into one plastic bag. Some rolls will be packed into carton and pallet. At last load into the container. |
Business information:
| Loading port: | Ningbo or Shanghai Port, China |
| Payment items: | TT, DP, L/C, Paypal |
| H.S. Code: | 70195900 |
| Leading time: | 15 days/40ft container |
| MOQ: | 20000m2 |
| Samples: | If A4 size piece sample, it is free; if big samples, it is not free |
